3 & 4 Point Bending Fixture – TA238

TA238 Flexural Fixture – 3 point bend & 4 point bend
2.5 kN (550 lb) and 10 kN (2250 lb)
Aluminum or Steel

Description

TA238 Flexural Fixture – 3 point bend & 4 point bend

  • 2.5 kN (550 lb) and 10 kN (2250 lb)
  • Aluminum or Steel
  • Base Width – 30 mm (1.4 in)
  • Minimum Span – 4 mm (0.16 in)
  • Base Options – 150 mm (6 in) and 300 mm (12 in)
  • Roller (length made to customer specifications)
    1, 2, 3, 4, 5, 6, 6.35, 8, 10, 12, 12.7 mm
  • Ideal for composites, plastics, sheeted metal, medical products, electronics and other materials

This fixture can be used to test and measure the flexural bending properties of a material.  It can be configured to meet many industry standards including ASTM D790, ASTM 6272 (deflection), ISO 178and other ASTM and ISO standards.

Additional information

List of Standards

ASTM D790, ASTM 6272 (deflection), ISO 178

Downloads

TA238 Flexural Bend Test
