Descripción
- TA170 grips are applicable for ropes and ribbons with max. load from 50 kN to 300 kN.
- According to its friction coefficient, the specimen will be twisted one or more times around the guide roller, before being fixed with clamping jaws.
- The guide rollers generate a slow notch free stress relief to prevent the breakage of the specimen in the clamping area.
- Other available options:
- Modified diameter of the guide roller
- 100kN, 150kN, 200kN versions
- Hydraulic versions
|
|
TA170-50 |
|
Applicable for |
Ropes, ribbons up to 50kN |
|
Tensile force |
50 kN |
|
Recommended rope diameter |
5 – 20 mm Ø |
|
Ribbons maximal width |
12 mm |
|
Minimal specimen length |
1500 mm |
|
Jaws surfaces |
Pyramid jaws, 1.2 x 45°, 58HRC Other surfaces on request |
|
Jaws clamping surface HxW |
70×30 mm |
|
Ø Guide roller |
162 mm Ø |
|
Temperature range* |
0°C – 70°C Other temperature ranges on request |
|
Body |
Steel, nickel-plated |
|
Weight |
13.9 kg each grip |
|
Ordering information/ Scope of delivery |
1 pair of grips without jaws |
